Home Lab v3.1: Ubiquiti Networks UniFi AP AC PRO

My home Internet access is critical not only to me, but to my whole family. Over the course of many years, I have gone through a variety of Internet configurations. Recently, I moved to the UniFi AP AC PRO from the ASUS RT-AC3200 for WiFi. I would like to discuss my requirements as I looked for a new WiFi solution and my thoughts so far. Read on to learn more!


When looking for a new WiFi solution, I considered the following requirements:

  • I wanted a device where I had flexibility on where I could install it
    • I have hard-wired Ethernet in my house
    • I have battery back-up in the basement
  • I did not want a consumer grade AP — as these had always failed me in the past
  • I did not want a dependency on other gear (i.e.¬†keep costs low)


After a ton of research, the UniFi AP AC PRO came up over and over. It also met my requirements:

  • It supports hard-wired Ethernet
  • It is powered over Power over Ethernet (PoE) and comes with an adapter
  • It is enterprise grade
  • It does not require any other gear though it does support other gear

NOTE: The UniFi AP AC PRO is an Access Point only (not a router). This was not a deal breaker for me as I could just disable the WiFi on my ASUS RT-AC3200 and continue to use it as a really expensive router (the primary issue with the ASUS was the WiFi).


It should be noted that I do not own a PoE switch. The reason why I went with the UniFi AP AC PRO is because it comes with an Ethernet to PoE adapter.

IMPORTANT: The single UniFi AP AC PRO comes with an Ethernet to PoE adapter, however the 3-pack of the UniFi AP AC PRO does not. You have been warned.

UniFi AP AC PRO Configuration

After making the decision on which AP to go with, it was time to configure it:

  • I found a location on the ground level that I thought would provide the optimal reception.
  • I added the Ethernet to PoE adapter in the basement closest to the switch so I could connect it to my battery back-up.
  • I downloaded the UniFi software for Mac — this interface is awesome compared to the consumer grade interfaces I am use to

NOTE: While the AP did glow as though it was in the configuration stage, the UniFi software was unable to find the AP. I had to unplug the AP and plug it back in for it to be discovered the first time.

  • After finding the AP, I was able to upgrade it to the latest firmware as well as give it a static IP address

Under Settings of the UniFi Controller, I made the following changes:

  • Site
    • Enabled: Automatically upgrade firmware
    • Enabled: Enable periodic speed test
    • Enabled: Enable remote syslog server (and pointed to Log Insight of course!)
  • Wireless Networks: used the same SSID and authentication as my ASUS RT-AC3200 (yes both devices were active at the same time)
  • Networks: used the same network and DHCP range as my ASUS RT-AC3200¬†(yes both devices were active at the same time)

And that was it! The last step was to log into the ASUS RT-AC3200 and disable the WiFi. After this point, all my wireless devices reconnected and I was good to go. I am happy to announce that all of the problems I had been experiencing with the ASUS RT-AC3200 are currently gone.

© 2016, Steve Flanders. All rights reserved.

6 comments on “Home Lab v3.1: Ubiquiti Networks UniFi AP AC PRO

Dan Y says:

Hey Steve, hope all is good with you! What was your issue with your wifi? I have some with mine so I was focused more on vlan isolation of that network to limit storms (if that was even the issue). Otherwise, was struggling to figure out why our signal had so many issues

Hey Dan — Thanks for the comment! I covered it a bit in my previous post: https://sflanders.net/2016/12/20/home-lab-v3-0-asus-rt-ac3200-issues/. WiFi over mobile was the chief complaint for me.

Todd H. says:

Hi Steve, I have a similar setup at home as well. Thought you might be interested in deploying the Unifi Cloud Controller as a Docker Container. I deployed it in my lab and it’s running on Photon OS. Check it out: http://rvavmware.com/photon-os-and-running-my-first-docker-container/.

This is awesome — thanks for sharing!

Mike Brown says:

Now we just need a UniFi content pack for log insight ; )

Indeed! I will look through the logs and see if I cannot whip one up.
